A garden path lit properly does something a floodlight never will: it shows you where to walk without announcing itself to the whole street. The wiring behind that glow is simple — low-voltage cable, a transformer, a handful of waterproof connections — but the difference between a run that still works years from now and one that flickers by October comes down to decisions made before the first spade hits the soil. Here is the order that works: plan the layout, size the parts, trench, connect, and test before you bury a thing.
Walk the path at night with a couple of fixtures propped in place, or set stakes and check them after dark. Path lights spaced 6 to 8 feet apart suit a narrow walkway; 8 to 10 feet works better along a wide drive or with taller fixtures. Perfectly even spacing is not the goal — steady rhythm is. If the path bends, let the fixtures follow the outside of the curve, where they read as a line of light.
Aim each fixture across the walkway rather than down its length. Lights pointed along the path throw glare at whoever is walking and leave hot spots under your feet. Keep fixtures on the planting side, a foot or so back from the edge; the lawn side loses them to mowers and string trimmers.
Count the fixtures on paper before you shop, and mark where each one lands — a corner, a step, the end of a bed. That sketch is what you size the transformer from, and it is what you carry to the store when you inevitably change your mind about spacing.
One planning trick saves voltage later: if you can, run the main cable so the transformer sits near the middle of the fixture line and split the circuit in two directions. Each half is then half as long, and voltage drop — the slow dimming of lights at the far end — stays manageable.
Add up the wattage of every fixture you plan to install. Modern LED path lights usually draw 2 to 5 watts each, so ten fixtures might total 20 to 50 watts. Buy a transformer rated at least 20 to 25 percent above that total, leaving room for the two lights you will inevitably want next spring. Nine 4-watt fixtures is 36 watts: a 60-watt transformer carries that comfortably, while a 45-watt unit runs hot and quits early.
Cable gauge is where most first attempts go wrong. Longer runs need heavier wire, and the chart on the transformer tells you the maximum run for each gauge — it is worth following. As a rule, 16-gauge is fine for short, lightly loaded runs, while 14- and 12-gauge hold voltage over longer distances.
Gather:
Low-voltage landscape cable is typically buried 6 to 8 inches deep — enough to keep it clear of ordinary gardening and aeration. Local rules vary, so confirm yours before assuming that depth is enough, and sleeve the cable in conduit wherever it crosses under a driveway or patio.
Slice the trench with a spade, lift the sod, and press the cable into the soil rather than dragging it, since pulling stretches the jacket and can break strands. Run one continuous length wherever possible and leave a service loop of 12 to 18 inches coiled at each fixture position. That slack is what lets you move a light six inches next year without splicing. Keep the run away from the edge where you trim and away from spots where water stands after rain. In a bed you plan to till, go deeper — a rototiller finds cable the way a mower finds hoses.
Nearly every failure in a low-voltage circuit happens at a connection. Wire nuts and electrical tape are not enough outdoors; use the silicone-filled connectors made for landscape lighting. Strip the cable cleanly, twist the strands so nothing strays, push the wires fully home, and close the connector tight. Give each one a firm tug before burying it — a connector that pulls apart now saves an afternoon of hunting later.
Where a fixture base has room, keep the connector inside it, above the soil line. Then bury the rest of the run.
If water can reach bare copper, it will — usually in the second winter, and usually at the fixture you can least reach.
Connect every fixture, then plug in the transformer with the cable still lying loose in the trench. Testing after dark, with moonlight and mulch as your judge, is the only test that tells the truth.
If the far end reads low, you have three levers: split the run into two, move up to a heavier gauge, or use a higher transformer tap. Many 12-volt transformers offer 12, 13, 14 and 15-volt taps for exactly this reason — stepping up costs nothing and buys back the drop.
Plug the transformer into an outdoor outlet protected by a GFCI, and mount it at least a foot above the ground on a post or wall, where air moves around it. Do not bury it in mulch or box it in — heat is what kills transformers. A photocell turns the circuit on at dusk; add a timer or an astronomical schedule so it runs four to six hours instead of until sunrise. Nobody needs a path lit at 3 a.m., and the fixtures last longer for the rest.
Symptoms point straight to causes:
Once a year, in fall, unplug the transformer and walk the run: press each connector, straighten bent stakes, re-aim whatever the season shifted, and rake with the cable in mind. Ten minutes in October is cheaper than a Saturday in January spent with a multimeter and a headlamp, hunting the one connector that quit.
